Solid Oxide Fuel Cell Materials

There are several different types of fuel cells, each using a different chemistry. Fuel cells are usually classified by their operating temperature and the type of electrolyte they use. Each type will have specific uses where it has advantages such as stationary power generation or mobile power sources. The main types of fuel cells include:

1. Polymer exchange membrane fuel cell(PEMFC)
2. Solid oxide fuel cell(SOFC)
3. Alkaline fuel cell(AFC)
4. Molten-carbonate fuel cell(MCFC)
5. Phosphoric-acid fuel cell(PAFC)
6. Direct-methanol fuel cell(DMFC)

NYACOL® materials are applicable to the Solid Oxide Fuel Cell(SOFC), primarily for the electrolyte, but also could be considered for sintering control of the base metal anode electrode.

Electrolytes are oxygen conducting dense ceramic layers, usually of zirconia or ceria. Doped types are usually used as they have improved properties at the operating temperatures of 600-800°C usually used. Electrolytes are tape casted from ceramic powders or deposited from colloidal dispersions as 10-20 micron layers.

Zirconia electrolytes are usually yttria stabilized zirconia but could be other types like scandia doped zirconia. NYACOL® offers ZRYS4 and ZRYS6 as stabilized zirconia nano-particle dispersions. These can be used alone or as additives to ceramic powders to aid in sintering control of the structure.

Ceria electrolytes are usually of doped compositions such as samaria doped ceria or gadolinium doped ceria. NYACOL® offers DP8020 as a samaria doped ceria colloidal dispersion for use as an additive to ceria powders for sintering control or as a starting material for colloidal system based deposition processes.

NYACOL® SN15CG, tin oxide dispersion, and NYACOL® Colloidal barium titanate may also be applicable for special processes in the anode. NYACOL® BtMin is a colloidal dispersion of 50nm barium titanate in a hydrocarbon carrier used to control sintering of nickel electrodes and provide a shrinkage match with the other components of the cell.

For more information, contact NYACOL® directly.

Looking for More Options?

In some cases our standard materials are not suitable for a customer’s particular application, or a different composition is required. In these cases, we will consider a custom development project with our customers. We generally proceed under a Non-Disclosure Agreement and we will do the project in such a way that the material can be readily scaled up.
